180 kW Motor Power Vibro Compaction Piling with Electric Power Type for Up To 30 Meters Depth Foundation Strengthening

Merknaam:	BVEM
Modelnummer:	BJVE-426-180Kw
MOQ:	1 set
Verpakking:	houten kist/houten pallet
Betalingsvoorwaarden:	L/C, T/T

Gedetailleerde informatie

Productbeschrijving

Gedetailleerde informatie

Plaats van herkomst:

China

Certificering:

ISO,CE

Document:

After-sales service verleend:

Ingenieurs beschikbaar voor onderhoud aan machines in het buitenland

Voorwaarde:

Nieuw

Gewicht:

2320 kg

Productnaam:

BJVE-426-180Kw

Motorvermogen:

180 kW

Afmeting (l*b*h):

3020 mm, 3300 * 650 * 650 mm

Garantie:

1 jaar of 2000 uur

Kleur:

groente

sollicitatie:

Verdichting en vervanging

Temperatuur:

20℃-+50℃

Motor:

300 kW/380 V/50 Hz

Vermogenstype:

Elektrisch

vermogen(w):

180 kW

Max. Omvang:

22 mm

maximaal snelheid:

1450 r/min

Breedte spanwijdte:

778MM

Tarief huidige:

356 A

Centrifugale kracht:

kN 280

Levering vermogen:

600 sets/jaar

Markeren:

180 kW Motor Power Vibro Compaction Piling

Electric Power Type Vibroflot Equipment

Up To 30 Meters Depth Bottom Feed Vibroflot

Productbeschrijving

Vibro Compaction Piling for Thermal Power Plant Foundations

Vibro Compaction Piling is an advanced soil improvement technology designed to enhance soil stability and load-bearing capacity through vibratory compaction. This innovative foundation treatment method reaches depths up to 30 meters, making it ideal for thermal power plant projects requiring robust foundation support.

Advanced Technology Features

Maximum Depth

Up to 30 meters

Outer Diameter

426 mm

Generator Power

200-600 KVA

Vibration Amplitude

14-28 mm

Technical Specifications

Product Name	Vibro Compaction Piling
Model Number	75kW-260kW
Rate Current	148-500 A
Soil Types	Sandy and Granular Soils
Construction Time	Rapid, Typically 1-2 Days Per 1000 Sqm
Condition	New

BVEM BJVE-426-180 Top Feed Vibroflot

The BVEM BJVE-426-180 Top Feed Vibroflot delivers exceptional performance for challenging ground conditions with its 180 KW power output. This advanced system dramatically reduces soil settlement and significantly increases soil bearing capacity through precise vibration technology.

Key Advantages: 1450 RPM rotation speed with inverter control for operational flexibility • Robust vibrator size (3300x650x650 mm) for durability • Suitable for both underwater and on-land applications

Customization & Ordering

Brand: BVEM
Place of Origin: China
Certification: ISO, CE
Minimum Order Quantity: 1 unit
Delivery Time: 15-30 days
Payment Terms: T/T, L/C

Technical Support & Services

On-site installation guidance
Comprehensive maintenance services
Professional troubleshooting assistance
Operator training programs
Spare parts supply and support

Also known as Vibratory Compaction Piling, Vibro-Compaction Piling, or Vibration-Compaction Piling, this technology provides a cost-effective and reliable solution for achieving strong foundations in thermal power plants and other critical infrastructure projects.
